Opis
| Standard version | DP1 300 / 300 D |
| Motor power | 300 W |
| Motor supply voltage | 12 V |
| Maximum pull | 370 Kg | 814 lb |
| Maximum working load | 120 Kg | 265 lb |
| Working load | 40 Kg | 88 lb |
| Current absorbtion @ working load (1) | 60 A |
| Maximum chain speed (2) | 26,3 m/min | 86.3 ft/min |
| Maximum chain speed @ working load (2) | 22,5 m/min | 73.8 ft/min |
| Weight – DP1 – [without drum] | 7,4 Kg | 16.3 lb |
| Weight – DP1 – [with drum] | 8,8 Kg | 19.4 lb |
| 1) | After an initial period of use |
| 2) | Measurements taken with a gypsy for a 6 mm chain |
| Standard version | DP1 500 / 500 D | |
| Motor power | 500 W | |
| Motor supply voltage | 12 V | 24 V |
| Maximum pull | 660 Kg | 1455 lb | |
| Maximum working load | 200 Kg 441 lb | 220 Kg 485 lb |
| Working load | 65 Kg 143 lb | 70 Kg 154 lb |
| Current absorbtion @ working load (1) | 80 A | 40 A |
| Maximum chain speed (2) | 25,2 m/min 82,7 ft/min | 25,2 m/min 82,7 ft/min |
| Maximum chain speed @ working load(2) | 18,5 m/min 59,7 ft/min | 19,3 m/min 63,3 ft/min |
| Weight – DP1 – [without drum] | 7,4 Kg | 16.3 lb | |
| Weight – DP1 D – [with drum] | 8,8 Kg | 19,4 lb | |
| HI-SPEED version | DP1 500 HS / 500 D HS | |
| Motor power | 500 W | |
| Motor supply voltage | 12 V | 24 V |
| Maximum pull | 600 Kg | 1323 lb | |
| Maximum working load | 170 Kg 375 lb | 200 Kg 441 lb |
| Working load | 65 Kg 143 lb | 70 Kg 154 lb |
| Current absorbtion @ working load (1) | 100 A | 50 A |
| Maximum chain speed (2) | 39 m/min 128 ft/min | 39 m/m 128 ft/min |
| Maximum chain speed @ working load (2) | 28,5 m/min 93,5 ft/min | 28 m/min 91,9 ft/min |
| Weight – DP1 – [without drum] | 7,4 Kg | 16.3 lb | |
| Weight – DP1 D – [with drum] | 8,8 Kg | 19.4 lb | |
| 1) | After an initial period of use |
