ESK – ACHERON

White painted horizontal axis winch. The ESK can use chains from 12 mm to 16 mm in diameter. With different drives and recommended for boats up to 32 m.

White painted horizontal axis winch. The ACHERON can use chains from 14 mm to 17,5 mm with stud link in diameter. With different drives and recommended for boats up to 37 m.

Kategorija: Oznaka:

Opis

ESK

ELECTRIC MOTOR2300W2700W3500W3000WHydraulic
MOTOR SUPPLY VOLTAGE24V24V24V230V/400VN/A
MAXIMUM PULL3300 Kg3500 Kg3900 Kg3900 Kg1300 Kg
LIFT WORKING LOAD1000 Kg1100 Kg1200 Kg1300 Kg1300 Kg
LINE SPEED13 mt/min13 mt/min13 mt/min13 mt/min13 mt/min
CURRENT ABSORBTION190 A200 A220 AN/AN/A
WEIGHT (WITH DRUM)N/AN/AN/AN/AN/A
WEIGHT (WITHOUT DRUM)100 Kg–> 125 Kg100 Kg–> 125 Kg100 Kg–> 125 Kg100 Kg–> 125 Kg100 Kg–> 125 Kg
CHAIN12mm ISO/ 13mm DIN766 – 14mm ISO – 16mm ISO – 16mm DIN766 – 16mm with stud link – 12,5 mm studlink – 14mm studlink – 1/2



ACHERON

ELECTRIC MOTOR3500W4000W5500W7500WHydraulic
MOTOR SUPPLY VOLTAGE24V230V/400V230V/400V230V/400VN/A
MAXIMUM PULL4800 Kg5000 Kg5500 Kg5800 Kg2600 Kg
LIFT WORKING LOAD1500 Kg1600 Kg2000 Kg2600 Kg2600 Kg
LINE SPEED12 mt/min12 mt/min12 mt/min12 mt/min12 mt/min
CURRENT ABSORPTION220 AN/AN/AN/AN/A
WEIGHT (WITH DRUM)N/AN/AN/AN/AN/A
WEIGHT (WITHOUT DRUM)200 Kg–> 250 Kg200 Kg–> 250 Kg200 Kg–> 250 Kg200 Kg–> 250 Kg200 Kg–> 250 Kg
CHAIN12mm ISO/13 DIN766 – 14mm ISO – 14mm stud link – 16mm ISO – 16mm DIN766 – 16mm stud link – 17,5mm stud link – 18mm ISO – 20mm ISO – 19,5mm studlink
