DEVON

Anticorodal anodized aluminium horizontal windlass. Devon can
use chains from 6 mm 8mm to 10 mm (DIN766 or ISO) in diameter.
With different drives and recommended for boats up to 15m. It comes as standard with chaincounter sensor on board.

Kategorija: Oznaka:

Opis

POWER1000W1000W1500W1500W
MOTOR SUPPLY VOLTAGE12V24V12V24V
MAXIMUM PULL1290 Kg1310 Kg1350 Kg1370Kg
LIFT WORKING LOAD150 Kg160 Kg180 Kg190 Kg
LINE SPEED25 mt/min25 mt/min26 mt/min26 mt/min
CURRENT ABSORPTION115 A60 A130 A70 A
WEIGHT (WITH DRUM)25Kg –>28 Kg25Kg –>28 Kg25Kg –>28 Kg25Kg –>28 Kg
CHAIN6mm ISO – 8mm ISO – 10mm ISO – 10mm DIN766 – 5/16
